峰值電流 | Dual range (10:1 )
60A peak to 60kA peak |
輸出 | ±6.0V peak |
高頻帶寬 (-3dB) | 1MHz (300mm coil), 600kHz (700mm coil) |
低頻帶寬 (-3dB) | Varies with model type <0.5Hz (refer to datasheet) |
精度(typ.) | Calibrated to ±0.3% with conductor central in the Rogowski loop |
| Typical variation with conductor position ±1.0% of reading |
工作溫度 | 0℃ to +40℃ (Integrator electronics) |
| –20℃ to +70℃ (Coil and cable) |
線圈長度 | 300, 500, 700 or 1000mm (custom lengths available) |
線圈厚度 | 8.5mm max. |
線圈最大絕緣值 | 2kV peak |
線纜長度 (線圈 到 積分器) | 2.5m (custom lengths available) |
供電 | Single 9V PP3 battery
Plus – 2.1/2.5mm socket for 12V to 24Vdc (±10%) DC supply) |
輸出負載 | > 100.0 k ohm (for rated accuracy) |
